In Part V we looked at the IPCC, an outlier organization, that claimed floods, droughts and storms had not changed in a measurable way globally in the last 50 -100 years (of course, some regions have seen increases and some have seen decreases, some decades have been bad, some decades have been good).
This puts them at a disadvantage compared with the overwhelming mass of NGOs, environmental groups, media outlets and various government departments who claim the opposite, but the contrarian in me found their research too interesting to ignore. Plus, they come with references to papers in respectable journals.
We haven’t looked at future projections of these events as yet. Whenever there are competing effects to create a result we can expect it to be difficult to calculate future effects. In contrast, one climate effect that we can be sure about is sea level. If the world warms, as it surely will with more GHGs, we can expect sea level to rise.
In my own mental list of “bad stuff to happen”, I had sea level rise as an obvious #1 or #2. But ideas and opinions need to be challenged and I had not really investigated the impacts.
The world is a big place and rising sea level will have different impacts in different places. Generally the media presentation on sea level is unrelentingly negative, probably following the impact of the impressive 2004 documentary directed by Roland Emmerich, and the dramatized adaption by Al Gore in 2006 (directed by Davis Guggenheim).
Let’s start by looking at some sea level basics.
Like everything else related to climate, getting an accurate global dataset on sea level is difficult – especially when we want consistency over decades.
The world is a big place and past climatological measurements were mostly focused on collecting local weather data for the country or region in question. Satellites started measuring climate globally in the late 1970s, but satellites for sea level and mass balance didn’t begin measurements until 10-20 years ago. So, climate scientists attempt to piece together disparate data systems, to reconcile them, and to match up the results with what climate models calculate – call it “a sea level budget”.
“The budget” means balancing two sides of the equation:
- how has sea level changed year by year and decade by decade?
- what contributions to sea level do we calculate from the effects of warming climate?
Components of Sea Level Rise
If we imagine sea level as the level in a large bathtub it is relatively simple conceptually. As the ocean warms the level rises for two reasons:
- warmer water expands (increasing the volume of existing mass)
- ice melts (adding mass)
The “material properties” of water are well known and not in doubt. With lots of measurements of ocean temperature around the globe we can be relatively sure of the expansion. Ocean temperature has increasing coverage over the last 100 years, especially since the Argo project that started a little more than 10 years ago. But if we go back 30 years we have a lot less measurements and usually only at the surface. If we go back 100 years we have less again. So there are questions and uncertainties.
Arctic ice melting has no impact on sea level because it is already floating. Water or ice that is already floating doesn’t change the sea level by melting/freezing. Ice on a continent that melts and runs into the ocean increases sea level due to increasing the mass. Some Antarctic ice shelves are in the ocean but are part of the Antarctic ice sheet that is supported by the continent of Antarctica – melt these ice sheets and they will add to ocean level.
Sea level over the last 100 years has increased by about 0.20m (about 8 inches, if we use advanced US units).
To put it into one perspective, 20,000 years ago the sea level was about 120m lower than today – this was the end of the last ice age. About 130,000 years ago the sea level was a few meters higher (no one is certain of the exact figure). This was the time of the last “interglacial” (called the Eemian interglacial).
If we melted all of Greenland’s ice sheet we would see a further 7m rise from today, and Greenland and Antarctica together would lead to a 70m rise. Over millennia (but not a century), the complete Greenland ice sheet melting is a possibility, but Antarctica is not (at around -30ºC, it is a very long way below freezing).
Why not use tide gauges to measure sea level rise? Some have been around for 100 years and a few have been around for 200 years.
There aren’t many tide gauges going back a long time, and anyway in many places the ground is moving relative to the ocean. Take Scandinavia. At the end of the last ice age Stockholm was buried under perhaps 2km of ice. No wonder Scandinavians today appear so cheerful – life is all about contrasts. As the ice melted, the load on the ground was removed and it is “springing back” into a pre-glacial position. So in many places around the globe the land is moving vertically relative to sea level.
In Nedre Gavle, Sweden, the land is moving up twice as fast as the average global sea level rise (so relative sea level is falling). In Galveston, Texas the land is moving down faster than sea level rise (more than doubling apparent sea level rise).
That is the first complication.
The second complication is due to wind and local density from salinity changes. So as an example, picture a constant sea level but Pacific winds change from W->E to E->W. The water will “pile up” in the west instead of the east, due to the force of the wind. Relative sea level will increase in the west and decrease in the east. Likewise, if the local density changes from melting ice (or ocean currents with different salinity) we can adjust the local sea level relative to the reference.
Here is AR5, chapter 3, p. 288:
Large-scale spatial patterns of sea level change are known to high precision only since 1993, when satellite altimetry became available.
These data have shown a persistent pattern of change since the early 1990s in the Pacific, with rates of rise in the Warm Pool of the western Pacific up to three times larger than those for GMSL, while rates over much of the eastern Pacific are near zero or negative.
The increasing sea level in the Warm Pool started shortly before the launch of TOPEX/Poseidon, and is caused by an intensification of the trade winds since the late 1980s that may be related to the Pacific Decadal Oscillation (PDO).
The lower rate of sea level rise since 1993 along the western coast of the United States has also been attributed to changes in the wind stress curl over the North Pacific associated with the PDO..
We can find a little about the new satellite systems in IPCC, AR5, chapter 3, p. 286:
Satellite radar altimeters in the 1970s and 1980s made the first nearly global observations of sea level, but these early measurements were highly uncertain and of short duration. The first precise record began with the launch of TOPEX/Poseidon (T/P) in 1992. This satellite and its successors (Jason-1, Jason-2) have provided continuous measurements of sea level variability at 10-day intervals between approximately ±66° latitude. Additional altimeters in different orbits (ERS-1, ERS-2, Envisat, Geosat Follow-on) have allowed for measurements up to ±82° latitude and at different temporal sampling (3 to 35 days), although these measurements are not as accurate as those from the T/P and Jason satellites.
Unlike tide gauges, altimetry measures sea level relative to a geodetic reference frame (classically a reference ellipsoid that coincides with the mean shape of the Earth, defined within a globally realized terrestrial reference frame) and thus will not be affected by VLM, although a small correction that depends on the area covered by the satellite (~0.3 mm yr–1) must be added to account for the change in location of the ocean bottom due to GIA relative to the reference frame of the satellite (Peltier, 2001; see also Section 13.1.2).
Tide gauges and satellite altimetry measure the combined effect of ocean warming and mass changes on ocean volume. Although variations in the density related to upper-ocean salinity changes cause regional changes in sea level, when globally averaged their effect on sea level rise is an order of magnitude or more smaller than thermal effects (Lowe and Gregory, 2006).
The thermal contribution to sea level can be calculated from in situ temperature measurements (Section 3.2). It has only been possible to directly measure the mass component of sea level since the launch of the Gravity Recovery and Climate Experiment (GRACE) in 2002 (Chambers et al., 2004). Before that, estimates were based either on estimates of glacier and ice sheet mass losses or using residuals between sea level measured by altimetry or tide gauges and estimates of the thermosteric component (e.g., Willis et al., 2004; Domingues et al., 2008), which allowed for the estimation of seasonal and interannual variations as well. GIA also causes a gravitational signal in GRACE data that must be removed in order to determine present-day mass changes; this correction is of the same order of magnitude as the expected trend and is still uncertain at the 30% level (Chambers et al., 2010).
The GRACE satellite lets us see how much ice has melted into the ocean. It’s not easy to calculate this otherwise.
The fourth assessment report from the IPCC in 2007 reported that sea level rise from the Antarctic ice sheet for the previous decade was between -0.3mm/yr and +0.5mm/yr. That is, without the new satellite measurements, it was very difficult to confirm whether Antarctica had been gaining or losing ice.
Historical Sea Level Rise
From AR5, chapter 3, p. 287:
Figure 1 – Click to expand
- The top left graph shows that various researchers are fairly close in their calculations of overall sea level rise over the past 130 years
- The bottom left graph shows that over the last 40 years the impact of melting ice has been more important than the expansion of a warmer ocean (“thermosteric component” = the effect of a warmer ocean expanding)
- The bottom right graph shows that over the last 7 years the measurements are consistent – satellite measurement of sea level change matches the sum of mass loss (melting ice) plus an expanding ocean (the measurements from Argo turned into sea level rise).
This gives us the mean sea level. Remember that local winds, ocean currents and changes in salinity can change this trend locally.
Many people have written about the recent accelerating trends in sea level rise. Here is AR5 again, with a graph of the 18-year trend at each point in time. We can see that different researchers reach different conclusions and that the warming period in the first half of the 20th century created sea level rise comparable to today:
The conclusion in AR5:
It is virtually certain that globally averaged sea level has risen over the 20th century, with a very likely mean rate between 1900 and 2010 of 1.7 [1.5 to 1.9] mm/yr and 3.2 [2.8 and 3.6] mm/yr between 1993 and 2010.
This assessment is based on high agreement among multiple studies using different methods, and from independent observing systems (tide gauges and altimetry) since 1993.
It is likely that a rate comparable to that since 1993 occurred between 1920 and 1950, possibly due to a multi-decadal climate variation, as individual tide gauges around the world and all reconstructions of GMSL show increased rates of sea level rise during this period.
Forecast Future Sea Level Rise
AR5, chapter 13 is the place to find predictions of the future on sea level, p. 1140:
For the period 2081–2100, compared to 1986–2005, global mean sea level rise is likely (medium confidence) to be in the 5 to 95% range of projections from process-based models, which give:
- 0.26 to 0.55 m for RCP2.6
- 0.32 to 0.63 m for RCP4.5
- 0.33 to 0.63 m for RCP6.0
- 0.45 to 0.82 m for RCP8.5
For RCP8.5, the rise by 2100 is 0.52 to 0.98 m..
We have considered the evidence for higher projections and have concluded that there is currently insufficient evidence to evaluate the probability of specific levels above the assessed likely range. Based on current understanding, only the collapse of marine-based sectors of the Antarctic ice sheet, if initiated, could cause global mean sea level to rise substantially above the likely range during the 21st century.
This potential additional contribution cannot be precisely quantified but there is medium confidence that it would not exceed several tenths of a meter of sea level rise during the 21st century.
I highlighted RCP6.0 as this seems to correspond to past development pathways with little CO2 mitigation policies. No one knows the future, this is just my pick, barring major changes from the recent past.
In the next article we will consider impacts of future sea level rise in various regions.
